Embedded Wireless Module
EM11
A compact 4K wireless video module for OEM integration into medical, industrial, and enterprise devices.
A compact 4K wireless video module for OEM integration into medical, industrial, and enterprise devices.
A small, low-weight embedded wireless module for OEM/ODM partners.
The EM11 module delivers 4K-30fps video, audio, and enhanced data channels through a board-to-board connector with an HDMI interface. Based on Amimon’s 3rd generation chipset, it is suitable for OEM/ODM partners who wish to integrate wireless video into their medical devices. The EM11 supports a MIMO of 2x5 with 20MHz or 40MHz bandwidth selection, creating a small form-factor wireless link for indoor and outdoor applications - suited to endoscopy camera control units, surgical monitors, fluoroscopy monitors, OR medical equipment, operating light cameras, wearable headlight cameras, and hand-held wireless camera systems.
Up to 4K at 30fps over a board-to-board connector with standard HDMI input and output interfaces.
Zero-delay wireless video transmission with a bidirectional data channel for control.
2x5 MIMO configuration with 20MHz or 40MHz selectable RF bandwidth for a compact, robust link.
Automatic and Dynamic Frequency Selection operate across the unlicensed 5GHz spectrum (5.1-5.9GHz), always choosing the cleanest channel.
Military-grade encryption with RSA-1024 key exchange protects the wireless link end to end.
SDK APIs for controlling link parameters, plus software management tools for users and operators.
Key performance parameters for system integration and evaluation.
| Parameter | Value |
|---|---|
| Video Resolution | Up to 4K-30fps |
| Latency | < 1mS |
| Supported RF Bandwidth | 40MHz or 20MHz |
| MIMO Configuration | 2x5 |
| AFS (Automatic Frequency Selection) | Ensures best channel selection |
| DFS (Dynamic Frequency Selection) | Operates on the entire unlicensed 5GHz spectrum (5.1-5.9GHz) |
| Antennas | Internal |
| Encryption | AES-256 (RSA-1024 for key exchange) |
| Number of Supported Receivers | 4 |
| Regulatory Approvals | FCC, CE, MIC, Canada, Korea |
Well suited for indoor and outdoor use across medical, construction/enterprise, UAV/UGV, and professional AV installation applications - including endoscopy camera control units, surgical monitors, fluoroscopy monitors, OR medical equipment, operating light cameras, wearable headlight cameras, and hand-held wireless camera systems.
Our engineering team is available to support your integration, answer technical questions, and provide evaluation units.
