Multi-Channel Wireless Hub
MD52x
Scalable wireless hub for large-scale patient monitoring
Scalable wireless hub for large-scale patient monitoring
Enterprise wireless infrastructure designed for the modern connected hospital.
The MD52x is a state-of-the-art wireless video transmission system engineered to provide seamless, real-time video connectivity between medical imaging sources-such as endoscopes, microscopes, and C-arms-and any display or recorder. The MD52x incorporates the next-generation Rocoto 2.0 protocol, transforming wireless video integration into a dynamic, fully controllable matrix for enhanced workflow efficiency.
A stable wireless link you can depend on, maintaining a solid connection in both clear line-of-sight and obstructed non-line-of-sight environments.
Take command of your video matrix with powerful, consolidated controls. Effortlessly manage your video feeds from a single, intuitive interface.
Distribute your content efficiently. Simultaneously stream your video to up to 4 receivers, reaching a wider audience without sacrificing performance.
Get up and running in minutes. Our fast and easy setup process requires no complex configuration, allowing you to focus on your content, not the technology.
Ideal for demanding environments. Supports up to 6 transmitters operating concurrently within the same Operating Room without interference.
Your privacy and data integrity are our priority. We employ a proprietary protocol and an encrypted video link with zero transfer of personalized data.
Key performance parameters for system integration and evaluation. The full specification sheet is available in Downloads.
| Parameter | Value |
|---|---|
| Video | |
| Video Inputs | 1x HDMI 2.0 Type-A |
| Video Outputs | 1x HDMI 2.0 Type-A |
| Color Sampling | RGB/YCbCr; 4:4:4 / 4:2:2 / 4:2:0 |
| Supported Resolutions | 2D: 4Kp23.98/24/25/29.97/30/50/59.94/60, 1080p23.98–60, 1080i50/59.94/60, 720p50/59.94/60 · 3D (SBS/Top-Bottom): 4Kp23.98–60, 1080p23.98–60 |
| Physical Attributes | |
| Dimensions | 7.9″L × 5.9″W × 1.6″H (200 × 150.1 × 40mm) |
| Wireless Video Network | |
| Rocoto 2.0 Network | Supports Rocoto Central Management Unit (CMU) for network management from a single device |
| Encryption | AES-256, ECC key exchange |
| Range | Up to 100 ft (30m) |
| Multicast | Can stream simultaneously to up to 4 receivers |
| Noise Rejection | Coexists with Wi-Fi and other 5GHz devices; up to 6 sets at the same location |
| Parameter | Value |
|---|---|
| Video | |
| Video Outputs | 1x HDMI 2.0 Type-A |
| Color Sampling | Same as the input signal |
| Supported Resolutions | 2D: 4Kp23.98/24/25/29.97/30/50/59.94/60, 1080p23.98–60, 1080i50/59.94/60, 720p50/59.94/60 · 3D (SBS/Top-Bottom): 4Kp23.98–60, 1080p23.98–60 |
| Physical Attributes | |
| Dimensions | 7.9″L × 5.9″W × 1.6″H (200 × 150.1 × 40mm) |
| Wireless Video Network | |
| Rocoto 2.0 Network | Supports Rocoto Central Management Unit (CMU) for network management from a single device |
| Encryption | AES-256, ECC key exchange |
| Range | Up to 100 ft (30m) |
| Multicast | Can switch between 4 transmitters |
| Noise Rejection | Coexists with Wi-Fi and other 5GHz devices; up to 6 sets at the same location |
Product brochures, specification sheets, and documentation.
Our engineering team is available to support your integration, answer technical questions, and provide evaluation units.
