Embedded Wireless Module
EM21
A high-performance embedded wireless video module built for the most demanding OEM integrations.
A high-performance embedded wireless video module built for the most demanding OEM integrations.
The most robust and highest-quality embedded wireless link in the EM-series.
The EM21 module delivers 4K video, audio, and enhanced data channels through a board-to-board connector with an HDMI interface. Based on Amimon’s 3rd generation chipset, it is suitable for OEM/ODM partners who wish to integrate wireless video into their medical devices. The EM21 supports a MIMO of 4x5 with 20MHz or 40MHz bandwidth selection, creating the most robust and highest-quality wireless link for indoor and outdoor applications - suited to endoscopy camera control units, surgical monitors, fluoroscopy monitors, OR medical equipment, operating light cameras, wearable headlight cameras, and hand-held wireless camera systems.
Up to 3840×2160 at 30fps over a board-to-board connector with standard HDMI input and output interfaces.
Zero-delay wireless video transmission with a bidirectional data channel for control.
4x5 MIMO configuration with 20MHz or 40MHz selectable RF bandwidth for the most robust link in the EM-series.
Automatic and Dynamic Frequency Selection operate across the unlicensed 5GHz spectrum (5.1-5.9GHz), always choosing the cleanest channel.
Military-grade encryption with RSA-1024 key exchange protects the wireless link end to end.
SDK APIs for controlling link parameters, plus software management tools for users and operators.
Key performance parameters for system integration and evaluation.
| Parameter | Value |
|---|---|
| Video Resolution | Up to 3840×2160 30fps |
| Latency | < 1mS |
| Supported RF Bandwidth | 40MHz or 20MHz |
| MIMO Configuration | 4x5 |
| AFS (Automatic Frequency Selection) | Ensures best channel selection |
| DFS (Dynamic Frequency Selection) | Operates on the entire unlicensed 5GHz spectrum (5.1-5.9GHz) |
| Antennas | Internal |
| Encryption | AES-256 (RSA-1024 for key exchange) |
| Number of Supported Receivers | 4 |
| Regulatory Approvals | FCC, CE, MIC, Canada, Korea |
Well suited for indoor and outdoor use across medical, construction/enterprise, UAV/UGV, and professional AV installation applications - including endoscopy camera control units, surgical monitors, fluoroscopy monitors, OR medical equipment, operating light cameras, wearable headlight cameras, and hand-held wireless camera systems.
Our engineering team is available to support your integration, answer technical questions, and provide evaluation units.
